Pre-compliance RF Shielded Test Enclosure Wireless IoT Device 5G WiFi Bluetooth Compact Chamber
Pre-compliance RF Shielded Test Enclosure
This compact pre-compliance RF shielded test enclosure provides a cost-effective solution for wireless device developers performing conducted and radiated EMC pre-compliance testing. Ideal for IoT devices, 5G modules, WiFi routers, Bluetooth products and mobile phones, this enclosure creates an isolated RF environment on your benchtop.
Design Features
- Compact benchtop design with modular 2mm galvanized steel construction
- Double electrically isolated (DEI) enclosure for maximum shielding effectiveness
- Movable platform with casters for flexible lab placement
- Filtered power inlet with EMI suppression
- RF connector panel with SMA, N-type and BNC feedthrough connectors
- Transparent RF-shielded viewing window with honeycomb mesh
- Internal LED lighting with filtered power
- Adjustable internal shelf for equipment placement
Shielding Performance
| Frequency Range | Attenuation |
|---|---|
| 14KHz (Magnetic Field) | 80dB |
| 100KHz | 100dB |
| 200KHz | 105dB |
| 50-103MHz (Plane Wave) | 110dB |
| 1-10GHz (Microwave) | 100dB |
| 10-40GHz | 80dB |
Standard Dimensions
| Model | Internal Dimensions (WxDxH mm) |
|---|---|
| Compact | 468 x 550 x 900 |
| Standard | 700 x 700 x 1200 |
| Large | 700 x 980 x 1800 |
All enclosures are fully assembled and tested in our facility before shipping. Custom dimensions, connector configurations, and accessories available. Contact us for pre-compliance testing solutions.
